HEICO-LOCK^®

PLUS

The easy-to-assemble combination of nut and washer.

HEICO-LOCK^® Plus offers an installation-friendly connection that prevents bolted joint self-loosening through the temporary connection of a nut and our HEICO-LOCK^® Wedge Lock Washer. Standard hexagon nuts according to ISO 4032 are combined with our proven HEICO-LOCK^® Wedge Lock Washers. This system secures your bolted connection, saves time and reduces costs.

Reduces part numbers within the connection since the nut and wedge lock washer are combined into one part
Easy, safe and fast installation in both serial production and in the field
Flexible attachment of the HEICO-LOCK^® Wedge Lock Washer and nut
Available in sizes M6 - M24, steel and stainless steel – additional dimensions and materials upon request.
Hexagon nuts according to ISO 4032

HEICO-LOCK® PLUS Kombination aus Mutter und Scheibe — HEICO-LOCK^® PLUS Kombination aus Mutter und Scheibe

Functional Principle

HEICO-LOCK^® Wedge locking system

An important feature of HEICO-LOCK ^® Wedge Lock Washers, setting them apart from other systems that are available, is the securing of the bolt fastening using preload force rather than friction

Wedge-shaped cams on the inside of the lock washers, radial teeth on the outside
Interlocking embedding of the radial teeth with the respective mating surface
(when tightening the bolted joint)
System movement only possible between the inner wedge shaped cams.
Movement across these wedge shaped surfaces effectively self locks the bolt
Increase in clamping force
